Introduction to AutoCAD Commands
AutoCAD is a computer-aided software design and drafting application developed by Autodesk, an American multinational corporation. AutoCAD runs on operating systems like Windows, macOS, iOS, Android. It is available in 13 different languages: English, German, French, Italian, Spanish, Korean, Chinese, Brazilian Portuguese, Russian, Czech, Polish, Hungarian. Before discussing the technicalities involved in AutoCAD, its commands, applications etc., let’s understand in a more distinguished way how was the world before and after AutoCAD. The below pictures can make any layman understand what AutoCAD is and how it has revolutionized the design industries.
3D animation, modelling, simulation, game development & others
Before AutoCAD:
After AutoCAD:
Simply put AutoCAD can be used in any industry where automation of design is required. AutoCAD is used in Automobile industry, Fashion industry by graphic designers, civil engineers etc. So far, we understood what is AutoCAD and how it is used in different industries. Now let’s go through how it works, how to use AutoCAD software, its commands, tips, and tricks to use it. To make the understanding of the software less complicated let us first into the basic commands, then to the intermediate and advanced commands lastly.
Basic AutoCAD Commands
- L – L stands for the line, the very basic command to draw a line.
Basics Of Autocad
- C – C to draw a circle
- REC – REC is for the rectangle, you can draw a rectangle in AutoCAD using this option
- ARC – This command is used to create the arc in AutoCAD
- POL – As the name suggests, it is to draw a polygon on the AutoCAD workspace. Using this option, you can draw a shape from 3 to 1024 sides.
- CO – This command is to copy any shape drawn on the workspace
- B – This command is used in AutoCAD to create a block and the properties of the block can also be defined in the Block window
- F – F stands for fillets in Auto CAD. This command is used to make sharp edges of the shapes round and smooth.
- SC – This command can be used to change the scaling of the selected object
- OP – This command is used in AutoCAD to open options Window, where most of the settings of AutoCAD are present.
Intermediate AutoCAD Commands
GROUP
To merge a set of objects into a single unit, you can use the group command of the AutoCAD too list. You can select the objects that you want to group and group them.
CAL
CAL is basically an inline calculator present in AutoCAD. Instead of using the external calculator, you can use the customized AutoCAD calculator which evaluates real and integral value equations and expressions.
QSELECT
QSELECT is a specification tool in AutoCAD. As the name suggests you can select the objects which fall into the specific category that you choose. This option is more useful when you have many objects with similar properties and you want to execute a function on all of them at the same time. In this case, you can use QSELECT and distinguish the objects, group them and execute the desired actions on them.
PAGESETUP
This AutoCAD command is used to change the page setup to landscape or portrait or another dimension. This can be done using the Page Setup Manager.
4.5 (835 ratings)
VPORTS
VPORTS command in AutoCAD is used to create multiple viewports in the layout
EATTEDIT
EATTEDIT stands for Enhanced Attribute Editor in AutoCAD. This command is used to edit already created attributes of the block. You can use EATTEDIT in command prompt to get this editor or go to InsertàEdit Attributesà Single or go to ModifyàObjectà The other easiest way to get the editor is to DoubleClick the block.
HYPERLINKS
Hyperlinks in AutoCAD is a very useful property but mostly not realized. Any object in AutoCAD, be a line or circle or a block, when you investigate its properties, you have a filed called hyperlink. You can use it to link it to any web page or even any local file on your hard drive. This AutoCAD command can be used for marking any references to the sources from which the information was drawn or to get any extra information about the object in the workspace
RENAME
As the name suggests, you can use this command to rename the selected object accordingly.
STANDARDS and CHECKSTANDARDS –
CAD standards are basically a set of rules for the user for a proper direction to use the different layers, colors, line types etc. You can set up your standards file and save them.
EATEXT –
This is a command to extract data from any object to an external file.
Advanced AutoCAD Commands
APPLOAD
This AutoCAD command is used to define applications at the time of starting AutoCAD.
DIMRADIUS
This command is used to create dimensions for circles and arcs.
LIGHT
The LIGHT command manages lighting effects on 3D models depending on the user’s interest
OOPS
This is a very useful command in AutoCAD. It restores the recently deleted objects
Tips and tricks to use AutoCAD Command
Autocad Basics Pdf
AutoCAD is a vast software which has n number of commands, tabs, instructions, standards to use. It could be a little difficult for a beginner to cope up with AutoCAD. One can use the below tips to use AutoCAD effectively.
Autocorrect
AutoCAD 2015 brings an option where once a command is mistyped it will autocorrect it to the most relevant command
Basics Of Autocad Electrical
Start tab
Whenever the AutoCAD workspace is opened the start tab displays where it contains tips, demonstration videos to help the user
File navigation dialog box
The File navigation dialog box is generally used to open, save, attach files. Now it comes with an option to remember the past sort order.
Learn Cad Drawing
Default dimension layer
Now we can setup a default dimension layer with a DIM layer system variable, with this option one can save time.
Conclusion – AutoCAD Commands
AutoCAD is a revolutionary software which has took automation and design to the next level. Its versions in 13 languages of the world prove how deeply it has reached the global industries. Learning AutoCAD is one of the very best job opportunities to learn and earn. You can get to know more about AutoCAD at https://www.autodesk.in/products/autocad/overview
